Guangzhou Western Packing Co., Ltd. is one of the most experienced manufacturers and suppliers of pet food pack machine seeds pouch packing machine in China. We warmly welcome you to buy high quality pet food pack machine seeds pouch packing machine made in China here from our factory. We also accept customized orders.

Product Details

Pet Food Pack Machine Seeds Pouch Packing Machine

The Industrial Machinery Pet Food Pack Machine Seeds Pouch Packing Machine is a state-of-the-art packaging machine designed to offer high-quality packaging solutions for a variety of products. The machine is primarily used for packaging pet food, seeds, and other small grains in pouch packs of different sizes.

seed counting and packaging machine

Product Performance

Pet Food Pack Machine Seeds Pouch Packing Machine

The Industrial Machinery Pet Food Pack Machine Seeds Pouch Packing Machine is designed to operate at high speeds, with a maximum capacity of up to 80 bags per minute. The machine comes equipped with advanced features such as an automatic bag feeding system, a photoelectric tracking system, and a touch screen control panel for easy operation. It also has a compact design, making it easy to install and operate.

Products Parameters

Bag Style	4-side seal	Range of measure	1-30/30-70g
Capacity	40-50 bag/min	Packing Material	Paper/Plastic, Plastic/Aluminum, Plastic Paper/Aluminum/Plastic, Filter paper Nonwoven mesh,etc.
Bag Size	(L)30-160mm, (W)25-100mm	Model Number	WP-880K
Dimension	1300x1200x2450mm(LWH)	Lanes	4/6/8/10/12 lanes
Power	3500w	Weight	550KG

Detail Images

Mechanical Structure

Vacuum feeder
Hoppers
Measurement cups
Touch screen HMI
Unwinding film guide tension structure
Control panel
Pulling roller
Vertical sealer
Horizontal sealer
Cutting knife
Conveyor
Foot cups

Machine Dimensions

Multi Quadrilateral seal grain packer
Food grade SS304 machine frame,all the contact parst SS316L. Stainless steel seamless tube 0.3mm

Part of the details

Bag forming step 1: Vertical sealing
It can make the bag pressure even,The grain is clear and the sealing is good
Bag forming step 2: Horizontal sealing
The cylinder pushes the sealing, when openingand closing. The room and force can beeasily adjusted

Mechanical advantage

Mechanical motion control the verticalancI the horizontal sealingMechanical structure is more direct,stablenot affected by the air source

Leakage switch

Detection to prevent collision between two objects;Detect the set position of the working machine and movethe limit position of the machine or parts; Check thestop position of the rotary body and the opening orclosing position of the valve.

seed counting and packaging machine seed multihead weigher packing machine

seed multihead weigher packing machine seeds pouch packing machine

Intermediate relay

Omron Intermediate relay, Used in circuits where current and voltage are unstable to protect circuitsand equipment, usually in automatic control circuits.

Servo filling

Prevent overcharge, ensure stable filling, no leakage of liquidmaterials,High efficiency, uniform density and high stabilityof molded products

seeds pouch packing machine pet food pack machine

Detail Images

pet food pack machine seasoning packaging equipment

Sample

Straight cutting
Zigzag cutting
Chain bag(optional)

Product Features

The product is seamlessly integrated with other machines such as seed counting and packaging machine, seed multihead weigher packing machine, seeds pouch packing machine, pet food pack machine, and seasoning packaging equipment for efficient and reliable performance.

Product Functionality

This Machine is designed to perform a variety of tasks. It can weigh, fill, seal, and pack products of different sizes and shapes. It is also equipped with precision sensors and advanced software to ensure accuracy and consistency in packaging.

Product Applications

It is used in industries such as pet food production, seed processing, and other industries that require small grain packaging. The machine is ideal for both small and large-scale production, depending on the industry's needs.

Company Introduction

Company Introduction

The Industrial Machinery Pet Food Pack Machine Seeds Pouch Packing Machine is produced by a leading manufacturer of packaging machines that has been in the industry for over 10 years. The company offers a wide range of packaging solutions that are designed to meet the needs of different industries.

FAQ

Q: What is the maximum capacity of the machine?

A: The Industrial Machinery Pet Food Pack Machine Seeds Pouch Packing Machine can pack up to 80 bags per minute.

Q: What products can the machine package?

A: The machine is suitable for packaging small grains such as pet food, seeds, and other similar products.

Q: Is the machine easy to operate?

A: Yes, the machine comes equipped with a touch screen control panel that makes it easy to operate.

Q: Can the machine pack products of different sizes and shapes?

A: Yes, the machine comes with a range of customizable settings that allow it to pack products of different sizes and shapes.

**Machine Component**
NO.	Item	Brand
1	PLC	SIEMENS(Germany)
2	HMI	SIEMENS(Germany)
3	Temperature controller	OMRON
4	Promiximity Switch	OMRON
5	Relay	OMRON
6	Powder Switch	SCHNEIDER
7	Pneumatic Component	Air Tec
8	Server Pull Motor	Delta
